HBS-3000 Digital Display Brinell Hardness Tester (3000 kgf Bench Machine)
Hardness Testers
Overview
The HBS-3000 is a digital display Brinell hardness tester with the full 3000 kgf load range. Brinell testing presses a hardened ball into the surface and measures the resulting indentation, and because the ball and the load are large the result averages a wide area of material – which is exactly what makes Brinell the right method for castings, forgings and coarse-grained metals.
The machine uses a weight adding force system with an LCD display of the test process, has on-board measurement, and can convert Rockwell, Vickers hardness values and tensile strength from the Brinell reading. A large LCD liquid crystal display with smart menu prompts makes it straightforward to operate, and an optional video or CCD image-processing system can automate the indentation measurement.
Technical Specifications
| Parameter | Value |
|---|---|
| Measuring range | 8-650 HBW |
| Maximum allowable height of sample | 235 mm |
| Test force | 1838.8, 2451.8, 4903.5, 7355.3, 9807, 29421 N (187.5, 250, 500, 750, 1000, 3000 kgf) |
| Distance from the indenter centre to the machine wall | 120 mm |
| Optical magnification | 20x |
| Minimum detection unit | 1 µm |
| Power supply | AC 220 V, 50/60 Hz |
| Overall dimensions | 705 × 215 × 880 mm |
| Weight | about 220 kg |
| Optional | Square workbench 400 × 150 × 30 mm; Brinell video measurement system; CCD Brinell image processing system |
Weight adding force system and on-board measurement
The HBS-3000 uses a weight adding force system that applies the load accurately and holds it stable, with the test process shown on the LCD. Six test forces from 187.5 kgf to 3000 kgf cover the standard Brinell loads used with different ball diameters and materials, and the measuring range of 8-650 HBW spans soft aluminium and copper alloys through to hardened steels. The machine also performs on-board measurement: it can convert Rockwell and Vickers hardness values and tensile strength from the Brinell result, and the measurement results can be printed at random. Its precision is in line with GB/T 231.2, ISO 6506-2 and ASTM E10.
Display, operation and optional imaging
A large LCD liquid crystal display with smart menu prompts makes the machine easy to operate, and the indentation is read with a 20x optical system whose minimum detection unit is 1 µm. For higher throughput an optional Brinell video measurement system or a CCD Brinell image-processing system can be fitted, which measures the indentation on screen and removes the manual reading step. The 120 mm throat between the indenter centre and the machine wall, together with the 235 mm maximum sample height, lets the machine handle a broad range of cast and forged parts.
Applications
The HBS-3000 is used to determine the Brinell hardness of ferrous metals, non-ferrous metals and bearing alloy materials, and it has a wide range of applications, especially for the precision measurement of parallel planes. Typical users are foundries and forges, bearing and alloy makers, steel traders and the inspection laboratories that qualify castings, forgings and heat-treated parts. A square workbench of 400 × 150 × 30 mm is available as an option for larger workpieces.
Frequently Asked Questions
What is the HBS-3000 used for?
It measures Brinell hardness – the hardness of ferrous metals, non-ferrous metals and bearing alloy materials – by pressing a ball into the surface at high load and measuring the indentation. It is especially suitable for castings, forgings and parallel planes.
What is the measuring range and test force of the HBS-3000?
The measuring range is 8-650 HBW and the test forces are 1838.8, 2451.8, 4903.5, 7355.3, 9807 and 29421 N, equal to 187.5, 250, 500, 750, 1000 and 3000 kgf.
Which standards does the HBS-3000 follow?
Its precision is in line with GB/T 231.2, ISO 6506-2 and ASTM E10, so Brinell results from the machine are comparable with other machines that follow the same standards.
Can the HBS-3000 measure and record results automatically?
The machine has on-board measurement, can convert Rockwell, Vickers hardness values and tensile strength, and can print the hardness measurement results at random. An optional video or CCD image-processing system can automate the indentation measurement.
What is supplied with the HBS-3000 as standard?
The standard configuration includes a Daping test bench, a Xiaoping test bench, a V-shaped test bench, tungsten carbide ball indenters in Ø10, Ø5 and Ø2.5 mm (one each) and two standard Brinell hardness blocks.
